The Asian Fab Kengeri master-plan decision starts with a genuine revision conflict. The current working brief records eight towers, while the supplied drawing visibly labels a smaller set and uses one label inconsistently. That mismatch is material because a tower count affects density, access, outlook, open-space relationships and phasing.
The residential layout on this page organises questions about arrival, pedestrian movement, service access, shared landscape and the relationship between homes and common facilities. The unresolved supplied drawing remains private, so a stack, view or orientation should be selected only from the current dated project sheet.
A decision-ready drawing should carry the legal project name, revision date, sanctioned status and a complete building schedule that reconciles with the registration record. It should also show entry points, fire access, basement ramps, service zones, open spaces, amenities, utilities and phase boundaries. If a selected unit is tied to a tower, that tower and stack should be identifiable on the same revision.
Until those items align, the strongest use of the master-plan route is preparation. Note which relationships matter to you, then ask for the current sanctioned sheet and walk the corresponding edges during a site visit. This keeps visual planning useful without turning an unresolved drawing into project geometry.
Residential Site-Planning Layout
Residential planning guide
Brochure and plan pack: How is the land used, and what will I look at?
Request the current approved master plan before comparing tower position, access or orientation.
The master-plan sheet and brochure pack with phasing marked
